Ubiquiti AF-5XHD airFiber 5XHD Backhaul Performance

Kode Produk: 33192

Referensi AI0918

Kondisi: Produk baru

GPS : External, Magnetic Base
Max Throughput : 1Gbps+
Max PPS : 2+ Million
Spectral Efficiency : 21,2 bps/Hz
Modulation Symbols : 4096 QAM

Lebih detail

Kirim ke teman
Kirim ke teman
Ubiquiti AF-5XHD airFiber 5XHD Backhaul Performance

GPS : External, Magnetic Base

Max Throughput : 1Gbps+

Max PPS : 2+ Million

Spectral Efficiency : 21,2 bps/Hz

Modulation Symbols : 4096 QAM
Penerima: :

Nama teman Anda ^* :

Alamat email teman Anda ^* :

^* Harus diisi

atau Batal
Bagikan di Facebook
Cetak

Info lainnya

Spesifikasi Ubiquiti AF-5XHD airFiber 5XHD Backhaul Performance

GPS	External, Magnetic Base
Operating Frequency	5150-5250MHz 5740-5850MHz
Power Supply	24V, 1A PoE Gigabit Adapter (Included)
Power Method	Dual Passive Power over Ethernet
Maximum Power Consumption	12W
Supported Voltage Range	20-50VDC
Mounting	airFiber X Mount (Rocket Mount Compatible) GPS Pole Mount (Included)
Certifications	FCC
Operating Temperature	-40 to 55° C (-40 to 131° F)
Data Port	(1) 10/100/1000 Ethernet Port
Configuration Port	(1) 10/100/1000 Ethernet Port
Processor	LTU IC
Maximum Throughput	1+ Gbps
Maximum Range	200+ km (Throughput and range values may vary depending on the environmental conditions)
Encryption	128-bit AES
Operating System	airOS F
Max TX Power	29 dBm (Dependent on Regulatory Region)
Frequency Accuracy	± 2.5 ppm without GPS Synchronization ± 0.2 ppm with GPS Synchronization
Channel Bandwidth	10/20/30/40/50/60/80/100 MHz Selectable

Berat dan ukuran Ubiquiti AF-5XHD airFiber 5XHD Backhaul Performance

Dimensions	224 x 82 x 48 mm
Weight	0.35 kg

Ringkasan Produk Ubiquiti AF-5XHD airFiber 5XHD Backhaul Performance

Ubiquiti Networks terus mengganggu pasar broadband nirkabel dengan teknologi revolusioner pada terobosan harga dengan memperkenalkan airFiber® XHD sistem radio airFiber modular yang akan melayani berbagai frekuensi dan dirancang agar kompatibel dengan berbagai antena Ubiquiti®.
