Biostar A880 GB AM3 AMD880G DDR3 Remote 50000

Spesifikasi produk Motherboard AMD Biostar A880 GB AM3 AMD880G DDR3 Remote 50000

Chipset

• AMD 880G / SB850

CPU SUPPORT

• AMD Phenom™ II X6 Processor
• AMD Phenom™ II X4 Processor
• AMD Phenom™ II X3 Processor
• AMD Phenom™ II X2 Processor
• AMD Athlon™ II X4 Processor
• AMD Athlon™ II X3 Processor
• AMD Athlon™ II X2 Processor
• AMD Sempron™ Processor
• Maximum CPU TDP (Thermal Design Power) : 125Watt

HT

• Support HT 5.2G

MEMORY

• Support Dual Channel DDR3 800/1066/1333(supportted by CPU model)/1600(OC) MHz
• 2 x DDR3 DIMM Memory Slot
• Max. Supports up to 8GB Memory

EXPANSION SLOT

• 1 x PCI-E x16 2.0 Slot
• 2 x PCI Slot

STORAGE

• 4 x SATA3 Connector
• Support SATA RAID: 0,1,5,10

USB

• 4 x USB 2.0 Port
• 2 x USB 2.0 Header

LAN

• Realtek RTL8111E - 10/100/1000 Controller

INTEGRATED VIDEO

• ATI Radeon™ HD4250 Graphics , Max. Memory Share Up to 512 MB

CODEC

• Realtek ALC662 6-Channel HD Audio

REAR I/O

• 1 x PS/2 Keyboard
• 4 x USB 2.0 Port
• 1 x HDMI Connector
• 1 x DVI Connector
• 1 x VGA Port
• 1 x RJ-45 Port
• 3 x Audio Connector

INTERNAL I/O

• 1 x Printer Header
• 2 x USB 2.0 Header
• 4 x SATA3 6Gb/s Connector
• 1 x Front Audio Header
• 1 x Front Panel Header
• 1 x S/PDIF-Out Header
• 1 x CPU Fan Header
• 1 x System Fan Header
• 1 x Serial Header
• 1 x CIR Header

DIMENSION

• Micro ATX Form Factor Dimension: 24.4cm x 20cm ( W x L )

OS SUPPORT

• Support Windows XP / Vista / 7

BUNDLE SOFTWARE

• BIO-Remote

ACCESSORIES

• 2 x SATA Cable
• 1 x I/O Shield
• 1 x CD Driver
• 1 x Quick Guide

FEATURES

• Windows 7 Compatible
• Supports AOD ACC
• Supports Phenom II x6
• Supports AM3
• Supports Solid capacitor
• Supports BIOS-Flasher
