Dell U2713HM monitor 27 in Widescreen (VGA + DVI-D + Display Port + USB 2.0 + HDMI)

Spesifikasi Dell U2713HM monitor 27 in Widescreen (VGA + DVI-D + Display Port + USB 2.0 + HDMI)

DISPLAY
Diagonal Viewing Size:

• 68.58 cm 27 inches (27-inch wide viewable image size)

Aspect Ratio

• Widescreen (16:9)

Panel Type, Surface:

• In-plane switching, anti glare with hard coat 3H

Optimal Resolution:

• 2560 x 1440 at 60 Hz

Contrast Ratio:

• 1000 to 1 (typical), Dynamic Contrast Ratio: 2 Million:1 (Max)

Backlight Technology:

• LED

Brightness:

• 350 cd/m2 (typical), 50 cd/m2 (minimum)

Response Time:

• 8ms (grey to grey)

Viewing Angle

• (178° vertical / 178° horizontal)

Color Support:

• Color Gamut (typical): sRGB >99%, 82% (CIE 1976)3 Color Depth: 16.78 million colors

Pixel Pitch:

• 0.23 mm

Display Type

• Widescreen Flat Panel Display

Device Type

CONNECTIVITY

• 1 Dual Link Digital Visual Interface connectors (DVI-D) with HDCP
• 1 DisplayPort 1.2 (DP)
• 1 High Definition Multimedia Interface (HDMI)
• 1 Video Graphics Array (VGA)
• USB 3.0 Hi-Speed Hub (with 1 USB upstream port and 4 USB downstream ports)
• 1 Audio out
• DC power connector for Dell Soundbar (AX510)
• Adjustability
• Height-Adjustable stand, tilt , swivel , pivot and built in cable-management

BUILT-IN DEVICES

• USB 3.0 Hi-Speed Hub (with 1 USB upstream port and 4 USB downstream ports) DC-out

SECURITY

• Security lock slot (cable lock sold separately)
• Anti-theft stand lock slot (to panel)

COLOR, SIZE AND WEIGHT
Dimensions (W x D x H)

• 639.3mm (25.17'') x 200.3mm (7.89'') x 424.3mm ~ 538.9mm (21.22'' ~ 16.70'')

Height with stand ( Compressed ~ Extended)

• 424.3 mm ~538.9 mm 16.70" ~ 21.22"

Height without stand

• 378.2 mm 14.89"

Preset Display Area (H x W)

• 596.7 mm x 335.7mm 23.49" x 13.22"

Weight (panel only - for VESA mount)

• 5.6 kg 12.44 lb

Weight (with packaging)

• 10.2 kg 22.67 lb

Service / Support Details

• 3-Year Advanced Exchange Service and Premium Panel Guarantee

Environmental and Regulatory

• ELECTRICAL

Voltage Required:

• 100 to 240 VAC / 50 or 60 Hz + 3Hz / 1.5 A (Max)

Power Consumption (Operational)

• 42W(typical) /100W(maximum) 4

Power Consumption Stand by / Sleep:

• Less than 0.5 W

ENVIRONMENTAL
Temperature Range Operating:

• 0° to 40°C (32° to 104°F)

Temperature Range Non-operating:

• Storage : -20° to 60° (-4° to 140° F)
• Shipping : -20° to 60° (-4° to 140° F)

Humidity Range Operating:

• 10% to 80% (non-condensing)

Humidity Range Non-operating:

• Storage : 5% to 90% (non-condensing)
• Shipping : 5% to 90% (non-condensing)

Altitude Operating:

• 3,048 m (10,000 ft) max

Altitude Non-operating:

• 10,668 m (35,000 ft) max

Compliant Standards
ENERGY STAR 5.1
EPEAT Gold

• TCO Certified Displays

Product Safety, EMC and Environmental Datasheets

• Dell Regulatory Compliance Home Page
• Dell and the Environment

What's Included

• Monitor with stand
• Power Cable
• DVI Cable
• USB Cable
• VGA Cable
• Cable Tie
• Drivers and Documentation media (incl Dell Display Manager software)
• Color Calibrated Factory Report
• Quick Setup Guide
• Safety Information

WARRANTY

• 3-Year Advanced Exchange Service and Premium Panel Guarantee.
