GIGABYTE-M52L-S3P

Kode Produk: 14

Referensi Gigabyte Discontinued

Kondisi: Produk baru

Part No: KG14

NVIDIA^® nForce 520LE chipset

Versi Lainnya : rev. 1.2rev. 1.0

Lebih detail

Kirim ke teman

Kirim ke teman

GIGABYTE-M52L-S3P

Part No: KG14

NVIDIA^® nForce 520LE chipset

Versi Lainnya : rev. 1.2rev. 1.0

Penerima: :

Nama teman Anda ^* :

Alamat email teman Anda ^* :

^* Harus diisi

atau Batal
Bagikan di Facebook
Cetak

Info lainnya

Prosesor	Support for Socket AM3/ AM2+/ AM2 processors: AMD Phenom™II processor/ AMD Phenom™ / AMD Athlon™II processor/ AMD Athlon™ processor/ AMD Sempron™ processor *Note: If you install AMD AM3/AM2+ CPU on AM2 motherbord, the system bus speed will downgrade from HT3.0(5200MT/s) to HT1.0(2000 MT/s) spec; however, the frequency of AM3/AM2+ CPU will not be impacted. Please refer "CPU Support List" for more information.
Hyper Transport Bus	2000 MT/s
Chipset	NVIDIA^® nForce 520LE chipset
Memori	4 x 1.8V DDR2 DIMM sockets supporting up to 16GB of system memory (Note 1) Dual channel memory architecture Support for DDR2 1066/800 MHz memory modules
Audio	Realtek ALC892 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF In/Out Support for CD In
LAN	Realtek RTL 8201 chip (10/100 Mbit)
Slot Tambahan	1 x PCI Express x16 slot, running at x16 2 x PCI Express x1 slot 4 x PCI slots
Antarmuka Penyimpanan	Integrated in the chipset: 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices 2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices Support for SATA RAID 0 and RAID 1 iTE IT8720 chip: 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB	Integrated in the chipset Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Konektor I/O Internal	1 x 24-pin ATX power connector 1 x 4-pin ATX 12V power connector 1 x floppy disk drive connector 1 x IDE connector 2 x SATA 3Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x CD In connector 1 x S/PDIF In header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x clearing CMOS jumper
Konektor Panel Belakang	1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x parallel port 1 x serial port 1 x coaxial S/PDIF Out 4 x USB 2.0/1.1 ports 1 x RJ-45 port 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
Pengontrol I/O	IT8720 chip
Pengawasan Hardware	System voltage detection System temperature detection CPU / System fan speed detection CPU / System overheating warning CPU / System fan failure warning CPU / system fan speed control (Note 2)
BIOS	2 x 8Mbit flash Use of licensed AWARD BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.0, SM BIOS 2.3, ACPI 1.0b
Fitur Unik	Support for @BIOS Support for Q-Flash Support for Xpress BIOS Rescue Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune (Note 3) Support for Auto Green Support for On/Off Charge
Paket Sofware	Norton Internet Security (OEM version)
Sistem Operasi	Support for Microsoft Windows 7/Vista/XP
Form Factor	ATX form factor; 30.5cm x 21.5cm
Catatan	(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB. (Note 2) Whether the CPU / system fan speed control function is supported will depend on the CPU cooler you install. (Note 3) Available functions in EasyTune may differ by motherboard model.
Keterangan	Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
