HP Designjet Z6200 Photo Printer

Spesifikasi produk HP Designjet Z6200 Photo Printer

Print

• Max. print speed
• 6 113 m²/hr (1225 ft²/hr)
• Print resolution Up to 2400 x 1200 optimised dpi
• Margins (top x
• bottom x left x
• right)
• 5 x 5 x 5 x 5 mm
• (0.2 x 0.2 x 0.2 x 0.2 in)
• Technology HP Thermal Inkjet

Image quality

• Colour accuracy Median < 1.19 dE2000, 95% of colours < 2.77 dE20007
• Short-term
• colour stability
• < 1 dE2000 less than 5 minutes8
• Long-term
• print-to-print
• repeatability
• Average
• < 0.5 dE2000, max < 1 dE20008

Media

• Handling Roll feed, automatic cutter, media bin
• Weight Up to 460 g/m² (114 lb) depending on media type
• Size 280 to 1067-mm (11 to 42-in) rolls
• Thickness Up to 0.56 mm (22 mil)

Applications

• Maps, Orthophotos, Posters, Banners, Mockups, Photos, Digital fine art, Proofs,
• Displays, POP/POS

Memory

• 32 GB (virtual)9
• , 160 GB hard disk

Connectivity

• Interfaces
• (standard)
• Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0 certified, EIO
• Jetdirect accessory slot
• Print languages Standard: HP-GL/2, HP-RTL, CALS G4
• Optional: Adobe® PostScript® 3™, Adobe PDF 1.7, TIFF, JPEG
• Drivers
• (included)
• HP-GL/2, HP-RTL drivers for Windows® (optimized for AutoCAD,
• from version 2000 to current), PostScript® Windows, Linux, and
• Mac drivers with optional PostScript®/ PDF Upgrade Kit

Dimensions
(w x d x h)

• Printer 1970 x 690 x 1370 mm (77.5 x 27.2 x 53.9 in)
• Shipping 2230 x 750 x 1200 mm (87.8 x 29.5 x 47.2 in)

Weight

• Printer 123 kg (271 lb)
• Shipping 210 kg (462 lb)

What’s in
the box

• HP Designjet Z6200 Photo Production Printer, spindle, printheads, introductory ink
• cartridges, maintenance cartridge, printer stand, media bin, 3-in spindle adaptor
• kit, quick reference guide, setup poster, startup software, power cord

Environmental
ranges

• Operating temperature: 5 to 40°C (41 to 104°F)
• Storage temperature: -20 to 55°C (-4 to 131°F)
• Operating humidity: 20 to 80% RH

Acoustic

• Sound pressure: 53 dB(A) (active); 38 dB(A) (standby)
• Sound power: 7 B(A) (active); 5.8 B(A) (standby)

Power
consumption

• 270 watts (printing); < 100 watts (ready);< 9 watts (<46 watts with embedded
• Digital Front End) (sleep); < 0.5 watts (off)
• Requirements: Input voltage (auto ranging): 100 to 127 VAC (+/- 10%), 5 A; 220 to
• 240 VAC (+/- 10%), 3 A; 50/60 Hz (+/- 3 Hz)

Certification

• Safety USA and Canada (CSA certified), EU (LVD and EN 60950-1
• compliant), Russia (GOST), Singapore (PSB), China (CCC), Argentina
• (IRAM), Mexico (NYCE), Korea (KC)
• Electromagnetic
• Compliant with Class A requirements, including USA (FCC rules),
• Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand
• (RSM), China (CCC), Japan (VCCI), Korea (MSIP)
• Environmental ENERGY STAR, WEEE, EU RoHS, China RoHS, REACH, FEMP, EPEAT
