HP A5500-48G SI Entry level L3 switch with RIP support 44x10 100 1000 ports 4 dual SFP ports 2 slots JD370A

Spesifikasi HP A5500-48G SI Entry level L3 switch with RIP support 44x10 100 1000 ports 4 dual SFP ports 2 slots JD370A

Input Voltage

• 100 - 240 VAC

Management features

• IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager; IEEE 802.3 Ethernet MIB

Manufacturer Warranty

• Limited Lifetime warranty: Advance hardware replacement with next-business-day delivery (available in most countries). See www.hp.com/networking/warrantysummary for duration details.;Electronic and telephone support: limited electronic and telephone support is available from HP refer to www.hp.com/networking/support for details on the support provided and the period during which support is available;Software releases: refer to www.hp.com/networking/support for details on the software releases provided and the period during which software releases are available for your product(s)

Ports

• 48 RJ-45 autosensing 10/100/1000 ports; 4 dual-personality ports; 2 port expansion module slots; Supports a maximum of 48 autosensing 10/100/1000 ports; Included

Power consumption

• 115 W (maximum)

Product dimensions (W x D x H)

• 17.32 x 11.81 x 1.72 in

Warranty

• Limited Lifetime warranty: Advance hardware replacement with next-business-day delivery (available in most countries). See www.hp.com/networking/warrantysummary for duration details.;Electronic and telephone support: limited electronic and telephone support is available from HP refer to www.hp.com/networking/support for details on the support provided and the period during which support is available;Software releases: refer to www.hp.com/networking/support for details on the software releases provided and the period during which software releases are available for your product(s)

Weight ( Imperial )

• 9.92 lb

Weight ( Metric )

• 4.5 kg

Extended specifications
Interfaces/Ports
Total Number of Network Ports

• 48

Stack Port

• Yes

Number of Network (RJ-45) Ports

• 48

Port/Expansion Slot Details

• 48 x Gigabit Ethernet Network
• 4 x Gigabit Ethernet Expansion Slot

Media & Performance
Network Technology

• 10/100/1000Base-T

Ethernet Technology

• Gigabit Ethernet

Fast Ethernet

• I/O Expansions

Number of SFP Slots

• 4

Expansion Slot Type

• SFP

Shared SFP Slot

• Yes

Network & Communication
Layer Supported

• 3

Management & Protocols
Manageable

• Yes

Management

• Intelligent Management Center
• Command-line interface
• Web browser management
• SNMP v1,2,3
• Telnet
• RMON 1,2,3,9
• IEEE 802.1Q VLAN
• IEEE 802.1p QoS
• DHCP
• Syslog

Memory
Standard Memory

• 256 MB

Memory Technology

• SDRAM

Flash Memory

• 32 MB

Power Description
Input Voltage

• 110 V AC
• 220 V AC

Power Source

• Power Supply

Physical Characteristics
Compatible Rack Unit

• 1U

Form Factor

• Rack-mountable

Height

• 1.7"

Width

• 17.3"

Weight (Approximate)

• 9.92 lb

Depth

• 11.8"

Miscellaneous
Green Compliant

• Yes

Green Compliance Certificate/Authority

• RoHS
• WEEE

Warranty
Limited Warranty

• Lifetime

Additional Warranty Information

• Next business day
• Phone support
