Mitsubishi XD3500U ANSI LUMENS 5000 XGA

Spesifikasi produk Projector Mitsubishi XD3500U ANSI LUMENS 5000 XGA

Display Technology

• 0.7" 1-Chip DMD

Resolution

• 1024 × 768 (Total 786,432 pixels)

Brightness

• 5000lm

Contrast

• 2500 : 1 (on / off)

Picture Size

• 40" ~ 300"

Throw Ratio

• 1.7 ~ 2.4

Source Lamp

• 264W (Shut-off Time 4000hr) with Low Mode 330W (Shut-off Time 2000hr) with Standard Mode

Computer Compatibility

• 640 × 480 ~ 1600 × 1200 True: 1024 × 768, Sync on Green available

Video Compatibility

• NTSC / NTSC4.43 / PAL (including PAL-M, N) / SECAM / PAL-60, Component Video: 480i/p (525i/p), 576i/p (625i/p), 720p (750p 50/60Hz), 1080i (1125i 50/60Hz), 1080p (1125p 50/60Hz), SCART (RGB+1V sync)

Pc Input Terminals

• mini D-sub 15pin × 1, 5 BNC × 1, DVI-D (with HDCP) × 1 Audio: stereo mini jack(ø3.5mm) × 3

Video Input Terminals

• Video: HDMI(ver.1.2) × 1, RCA × 1 or BNC × 1, S-Video(4pin) × 1 or S-Video Y/C(BNC) Audio: RCA (L, R) × 2

Output Terminals

• RGB: mini D-sub 15pin × 1, DC Out: 5V 1.5A (MAX) Audio: stereo mini jack (ø3.5mm) × 1

Communication Terminals

• LAN (RJ-45) × 1, RS-232C:D-sub 9pin × 1, USB × 1 (Mouse control), Wired remote in: stereo mini jack (ø3.5mm) × 1 Wired remote out: stereo mini jack (ø3.5mm) × 1

Audio Speaker

• 10W mono

Fan Noise

• 26dBA (Lamp Low Mode)

Dimensions(W×H×D)

• 450 × 187 × 373mm/17.7 × 7.4 × 14.7 in (excluding terminal cover)

Weight

• 10.3kg /22.7lbs (excluding detachable terminal cover)

Power Supply

• AC100 - 240V, 50/60Hz

Option

• Lamp: VLT-XD3200LP Lens: OL-XD2000SZ, OL-XD2000LZ, OL-XD2000TZ, OL-XD2000FR
