ROLAND VersaCamm VP-540i

Spesifikasi Produk ROLAND VersaCamm VP-540i

Features

CMYK - four colors with 4 printheads

Choose from two type of inks

ECO-SOL MAX, mild solvent ink and FPG2 aqueous inks

High productivity and professional quality resoult

Printing Technology      Piezoelectric inkjet

Max. Resolution           1440 dpi

Number of Ink Colours 4 (cyan, magenta, yellow, and black)

Ink Type

Exclusive Roland ECO-SOL MAX

Exclusive Roland ECO-SOL MAX FPG2 Aqueous Ink

Ink Capacity

220 cc or 440 cc

Max. Printing Width

53 in (1346 mm)

Media

Width

210 to 1,371 mm (8.3 to 54 in.)

Thickness

Maximum 1.0 mm (39 mil) with liner, for printing Maximum 0.4 mm (16 mil) with liner and 0.22 mm (9 mil) without liner, for cutting

Roll outer diameter

Maximum 180 mm (7 in.)

Roll weight

Maximum 30 kg (66 lb.)

Core diameter

50.8 mm or 76.2 mm (2 in. or 3 in.)

Connectivity

Ethernet (10BASE-T/100BASE-TX, automatic switching)

Cutting Speed

10 to 300 mm/s

Blade Force

30 to 300 gf

Blade offset :

0 to 1.5 mm (0 to 0.059 in)

O/S Compatibility

Operating system

Windows® 7 Professional or Ultimate (32-bit); Windows Vista® Business/Ultimate Service Pack 1 (32-bit); Windows Vista® Business/Ultimate (32-bit); Windows® XP Professional Service Pack 2 or later; or Windows® 2000 Service Pack 4

CPU

Core™2 Duo, 2.0 GHz or faster recommended

RAM

1 GB or more recommended (Windows7 andVista: 2 GB or more recommended)

Video card and monitor

A resolution of 1280 x 1024 or more recommended

Free hard-disk space

40 GB or more recommended

Hard-disk file system

NTFS format

Optical drive

DVD-ROM drive

Power Consumption

Automatic sleep feature

During Operation :

Approx. 1030 W

Sleep Mode :

Approx. 17 W

Power requirements

AC 100 to 120 V ±10%, 7.6 A, 50/60 Hz or

AC 220 to 240 V ±10%, 3.9 A, 50/60 Hz

Acoustic noise level

During operation : 64 dB (A) or less

During standby : 40 dB (A) or less

Dimension

2310(W) x 740(D) x 1125(H) mm

Weight

112 kg (247 lb.)

Package Content

Contents may vary

Warranty          1-year Limited Warranty by Authorized Distributor a
