Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

Kode Produk: 28870

Referensi WA/ANG0316

Kondisi: Produk baru

tegrated Power Over Ethernet Ditambah
Terbukti Kinerja dan Keandalan
Konfigurasi dan Manajemen Mudah
Canggih Keamanan Jaringan
Dukungan IPv6
peningkatan QoS
Keamanan ditingkatkan
Memenuhi EEE ( Hema

Lebih detail

Kirim ke teman
Kirim ke teman
Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

tegrated Power Over Ethernet Ditambah

Terbukti Kinerja dan Keandalan

Konfigurasi dan Manajemen Mudah

Canggih Keamanan Jaringan

Dukungan IPv6

peningkatan QoS

Keamanan ditingkatkan

Memenuhi EEE ( Hema
Penerima: :

Nama teman Anda ^* :

Alamat email teman Anda ^* :

^* Harus diisi

atau Batal
Bagikan di Facebook
Cetak

Info lainnya

Spesifikasi Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

Network Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3z IEEE 802.3x IEEE 802.3ad IEEE 802.3az IEEE 802.3af IEEE 802.3at IEEE 802.1d IEEE 802.1q/p IEEE 802.1X
Number of Ports with PoE+ Support	16
Memory	128 MB
LEDs	System (blue), Link/Act/PoE (green/green)
System Power Consumption without PoE+	110V:19.47W 220V:19.39W
Forwarding Rate	26.79 Mpps
Switching Capacity	36 Gbps
MAC Address Table Size	8K
Jumbo Frame (FE, GE)	9K
Fans	One, 8,200 rpm
Power Dedicated to PoE+	125W
Power Input	100–240V 50-60 Hz (2.5A max)
Operating Temperature	0 to 50°C (32 to 122°F)
Storage Temperature	-40 to 70°C (-40 to 158°F)
Operating Humidity	10 to 90% RH
Storage Humidity	10 to 90% RH (non-condensing)
Spanning Tree	IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree
Link Aggregation	IEEE 802.3ad LACP, up to 4 groups with up to 8 ports per group
VLAN	Port-based and 802.1q tag-based VLANs, Management VLAN, Guest VLAN support, Dynamic VLAN assignment via Radius server with 802.1x client authentication
Number of VLANs Supported	128 active VLANs (4,096 range)
Auto Voice VLAN	VLAN Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels
IGMP Snooping	IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups
HOL Blocking Prevention	Head of line (HOL) blocking prevention
Port Mirroring	Traffic on multiple ports can be mirrored to another port for analysis with a network analyzer
Security Features	802.1x Radius authentication DHCP snooping IP-MAC binding Port security supports limited dynamic lock and locked MAC address Management access control
Storm Control	Broadcast, flooding, and multicast
RMON	Embedded remote monitoring (RMON) software agent support for enhanced traffic management, monitoring, and analysis
Management Interface	HTTP HTTPS
Other Management	Telnet (Menu CLI), DHCP client, system log, configuration unload and backup via HTTP or TFTP, PING, dual images, SNTP
SNMP	Version 1 Version 2c
Firmware Upgrade	Web Browser (HTTP/HTTPS) TFTP
QoS - Class of Service	Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based
Combo Ports (RJ45 + SFP)	2 combo on ports g17, g18 Copper FE/GE Ports (RJ45): g01–g08, g09-g16
Green Power Mode	EEE+, Short Reach + Energy Detect
QoS - Priority Levels	4 hardware queues
QoS - Scheduling	Priority queuing and weighted round robin (WRR)
Total System Ports	18GE

Berat dan ukuran Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

Dimensions (LxWxH)	440 x 200 x 44 mm (17.3 x 7.9 x 1.7 in.)
Weight	2.784 kg (6.12 Ibs.)

Isi Paket Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

Ringkasan Produk Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

Dirancang untuk manajemen kelas bisnis , keamanan , kecepatan , dan kualitas layanan .

Integrated Power Over Ethernet Ditambah
Terbukti Kinerja dan Keandalan
Konfigurasi dan Manajemen Mudah
Canggih Keamanan Jaringan
Dukungan IPv6
peningkatan QoS
Keamanan ditingkatkan
Memenuhi EEE ( Hemat Energi Ethernet ) standar 802.3az

Ringkasan Produk Linksys LGS318P 18-Port Business Gigabit Smart Switch PoE+

KUALITAS PELAYANAN ( QoS ) prioritas lalu lintas
Banyak QoS fitur memprioritaskan lalu lintas , ideal untuk suara dan video aplikasi real-time & bandwidth yang grafis tinggi atau upload video dan download .

TERPADU Power over Ethernet PLUS ( POE + )
Membuat instalasi sederhana dan murah dengan menghilangkan kebutuhan untuk kabel listrik tambahan dan outlet listrik di dekatnya . Kompatibel dengan standar 802.3af ( PoE ) .

FITUR NETWORK EKSPANSI
Membangun mesh switch mudah dengan fitur seperti Spanning Tree Protocol ( STP ) dan Storm Control . Mereka membantu mengontrol direncanakan atau kabel yang tidak disengaja loop sehingga Anda dapat memperluas jaringan Anda dengan percaya diri .

ADVANCED KEAMANAN JARINGAN
Memastikan data lolos ke klien yang berwenang dengan Pelabuhan otentikasi dan keamanan pelabuhan berbasis MAC . Canggih DHCP mengintip dan IP - MAC mengikat fungsi menjamin integritas jaringan dan membantu mencegah serangan .
